PARTS LIST
34 Capacitor (Fan Motor) 9704305060 9704305060
40 Water Seal Plate 9369684005 9369684005
45 Bracket (Eva. ) 9369372001 9369372001
61 Decoration Plate-F 9368757014 9368757014
63 Front Panel 9368540012 9368540012
69 Louver 9368560010 9368560010
69-1 Louver Base-A 9368558017 9368558017
69-2 Louver Base-B 9368559014 9368559014
74 Air Filter 9368552008 9368552008
92 Link Holder 9368563004 9368563004
108 Base 9369209017 9369209017
122 Bearing Assy 9368574000 9368574000
127 Drain Hose 9367695003 9367695003
146-1 Evaporator-A Assy 9371199009 9371199009
146-2 Evaporator-B Assy 9369373008 9369373008
158 Joint Pipe Assy 9370301007 9370301007
160-1 Rear Drain Pan 9368547004 9368547004
163-2 Thermistor Spring-A 313728262708 313728262708
164 Fan Motor Assy-IN 9601388012 9601388012
169 Cross Flow Fan Assy 9368586003 9368586003
321 Flap 9368544010 9368544010
338 Motor Holder-A 9368550004 9368550004
126 Front Drain Pan 9370932010 9370932010
178-1 Rubber (Motor) 9368575007 9368575007
199 Step Motor 9900020019 9900020019
220 Water Plate 9368569006 9368569006
233 Power Transformer 9900069018 9900069018
236 Controller PCB Assy 9704714107 9704714114
(EZ-0032AHSE-C) (EZ-0032BHSE-C)
241 Remocon Holder 9305642014 9305642014
240 Remote Control Unit 9371190112 9371190112
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASY30LBA-WASY24LBA-W
ASY30LBA-WASY24LBA-W
182004.06.29
401 Wall Hook Bracket 9368579005 9368579005
408 Louver Link 9368562007 9368562007
425 Earth Plate 9368580001 9368580001
428 Screw Cover 9368576011 9368576011
435 Louver Spring 9368613006 9368613006
473 Pipe Holder 9368565008 9368565008
473-1 Cord Holder 9368566005 9368566005
506 Louver Rod 9368561017 9368561017
514 Control Box 9368543006 9368543006
522-1 Sector Gear 9368556006 9368556006
522-2 Pinion Gear 9368557003 9368557003
522-3 Flap Spring 9368612009 9368612009
557 Diffuser Spring 9368587000 9368587000
574-1 Evaporator Support-R 9368549008 9368549008
574-2 Evaporator Support-L 9368548001 9368548001
588 Evaporator Holder 9368775001 9368775001
684 Motor Base 9368555009 9368555009
707 Display Cover 9368564001 9368564001
735 Distributor Assy 9373249016 9373249016
759 Intake Grill-G 9368541040 9368541040
764 Drain Cap 9367677009 9367677009
815 Terminal 9306489106 9306489106
846 Relay G5NB-1A 9900007010 9900007010
855 Cover Display 9369264016 9369264016
855-1 Cover Display-B 9369594014 9369594014
855-2 Cover Display-C 9369683015 9369683015
938 Control Box Cover-R 9369631009 9369631009
942 Control Box Cover 9368611002 9368611002
960 Diffuser Assy 9368545017 9368545017
963-1 Fan Guard Holder 9368554002 9368554002
385 Indicator PCB Assy 9702307011 9702307011
338-1 Motor Holder-B 9368551001 9368551001
338-2 Motor Holder-C 9368769000 9368769000
