REFRIGERANT SYSTEM DIAGRAM
CAPILLARY
RECEIVER
TUBE
COMPRESSOR
ACCUMULATOR
HEAT COOL
STRAINER
2-WAY
VALVE
EXPANSION
VALVE
3-WAY
VALVE
4-WAY VALVE
OUTDOOR UNIT
INDOOR UNIT
Models : ASY24LBA-W / AOY24LMAL
ASY30LBA-W / AOY30LMAL
4
2004.05.28
HEAT EXCHANGER
HEAT EXCHANGER
HEAT EXCHANGER
