Fujitsu ASY50-KM Service Manual

¢ Wall mounted type (For KMTB, KMTE, KMCC, KMCE, and
KMCF)
 Fan speed
Indoor fan speed is defined as below.
Operation
mode
Fan mode
Speed (rpm)
ASYG18KMTB
ASYG18KMTE
ASYG07KMCC
ASYG07KMCE
ASYG07KMCF
ASYG09KMCC
ASYG09KMCE
ASYG09KMCF
ASYG12KMCC
ASYG12KMCE
ASYG12KMCF
ASYG14KMCC
ASYG14KMCE
ASYG14KMCF
Heating
POWERFUL 1,400 1,230 1,270 1,310 1,400
HIGH 1,300 1,160 1,200 1,240 1,330
MED+ 1,230 1,060 1,060 1,120 1,160
MED 1,130 970 990 1,050 1,100
LOW 900 820 830 900 910
QUIET 760 650 650 650 670
Cool air
prevention
650 570 570 570 580
S-LOW 520 420 420 420 470
Cooling/
Fan
POWERFUL 1,400 1,140 1,200 1,200 1,320
HIGH 1,260 1,070 1,130 1,130 1,250
MED 1,080 920 940 940 1,020
LOW 900 780 780 780 810
QUIET 760 630 630 630 630
Soft quiet
650*
1
490*
1
490*
1
490*
1
510*
1
S-LOW
520*
2
420*
2
420*
2
420*
2
470*
2
Dry
X zone: 760
J zone: 670
X zone: 630
J zone: 630
X zone: 630
J zone: 630
X zone: 630
J zone: 630
X zone: 630
J zone: 630
Operation
mode
Fan mode
Speed (rpm)
ASYG07KMTB ASYG09KMTB ASYG12KMTB ASYG14KMTB
Heating
POWERFUL 1,210 1,250 1,270 1,360
HIGH 1,140 1,180 1,200 1,290
MED+ 1,040 1,040 1,100 1,160
MED 950 970 1,030 1,100
LOW 800 810 880 910
QUIET 630 630 630 670
Cool air
prevention
550 550 550 580
S-LOW 400 400 400 470
Cooling/
Fan
POWERFUL 1,120 1,180 1,180 1,320
HIGH 1,050 1,100 1,110 1,250
MED 900 920 920 1,020
LOW 760 760 760 810
QUIET 550 550 550 580
Soft quiet
470*
1
470*
1
470*
1
510*
1
S-LOW
400*
2
400*
2
400*
2
470*
2
Dry
X zone: 550
J zone: 550
X zone: 550
J zone: 550
X zone: 550
J zone: 550
X zone: 580
J zone: 580
*1: Fan mode only
*2: Cooling mode only
3-1. Indoor fan control - (04-38) - 3. Fan control
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
