2013.04.25 11
INDOOR UNIT
WALL MOUNTED
ASYG18LFCA
ASYG24LFCA
ASYG24LFCC
998 mm
238 mm
320 mm
520 mm
590 mm
721 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LMCA
ASYG09LMCA
ASYG12LMCA
ASYG14LMCA
268 mm
15.8 to 16.7
203 mm840 mm
Drain hose
Diameter
Outside
Inside : 13.8 mm
600 mm
