Item no. Part no. Part name Service part
100 9316412057 Drain pan assy ♦
101 9316217010 Limit switch cover ♦
102 9316218017 Key top ♦
103 9316177017 Drain cap ♦
104 9711683007
Wire with connector
(Refrigerant leak detect sensor—P410 on Main PCB)
♦
105 9901089008 Refrigerant leak detect sensor ♦
106 9384838001 Sensor cover seal ♦
107 9384709004 Sensor cover ♦
108 9314147029 Drain hose assy ♦
109 9316384019 Drain hose holder ♦
110 9312156016 Bushing B ♦
111 9303529010 Bushing A ♦
112 9316334014 L and R louver Z ♦
113 9316335011 Joint Z ♦
114 9315282019 Spacer D ♦
115 9316219014 Stopper ♦
116 9316374010 Lower cover ♦
117 9316386013 Drain pan cover B ♦
118 9316216013 Damper ♦
119 9316274013 Drain pan cover F ♦
120 9316918009 Fan guard Z ♦
121 9900384074 Step motor (Damper lock R) ♦
122 9900384067 Step motor (Damper lock L) ♦
123 9900424015 Micro switch (Limit) ♦
124 9900384050 Step motor (Damper) ♦
a — Drain pan U —
b — Drain pan Z —
3-6. Floor type - (02-57) - 3. Indoor unit parts list
