Item no. Part no. Part name Service part
1 9322556073 Top panel assy ♦
2 9322811042 Protective net ♦
3 9322552266 Cabinet right assy ♦
4 9322554031 Terminal cover assy ♦
5 9322570079 Switch cover assy ♦
6 9900369064 Terminal (Power) ♦
7 9900369071 Terminal (Inner) ♦
8 9711609007 Indicator PCB ♦
9
9711674005 Main PCB (For 18 model) ♦
9711674012 Main PCB (For 24 model) ♦
10
9900565008 Thermistor assy (Outdoor temp.) (For 18 model) ♦
9900565060 Thermistor assy (Outdoor temp.) (For 24 model) ♦
11
9900727048 Thermistor assy (For 18 model) ♦
9900727116 Thermistor assy (For 24 model) ♦
12
9900985035 Compressor thermistor (For 18 model) ♦
9900985011 Compressor thermistor (For 24 model) ♦
13 9709685778 Inverter PCB ♦
14 9322421043 Heat sink ♦
15 9322144003 Drain pipe ♦
16 9322322043 Base assy ♦
17 9322386007 Cushion rubber ♦
18 9810028006 Thermistor stopper ♦
19 9319151007 Emblem ♦
20 9322149008 Blow grille ♦
21 9322555267 Front panel assy ♦
22 9322150004 Propeller fan ♦
23 9603601003 Brushless motor ♦
24 9322553034 Motor bracket assy ♦
25 9900041014 Thermistor (Heat exchanger) ♦
26 9317089791 Condenser total assy ♦
a — Inverter assy —
b — Hair pin cushion —
4-1. Models: AOYG18KBTA3 and AOYG24KBTA3 - (02-59) - 4. Outdoor unit parts list
