¢ Models: ASYG07KMCC, ASYG09KMCC, ASYG12KMCC, and
ASYG14KMCC
Unit: mm
(834)
Outline of indoor unit
327
273273 54
(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
834
270
222
3.0
2-4. Wall mounted type - (01-27) - 2. Dimensions
