¢ Intake grille
Parts No.DescriptionRef
11
12
13
14
Intake grille
Long Life Filter
Hook bracket
Grille hook
9382863005
9375533014
9375546014
9375532031
12
13
14
11
2-1. Model: UTG-UFYF-W - (02-3) - 2. Cassette grille (optional part) parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
