31
32
33
Item no. Part no. Part name Service part
31 9387479041 U/D louver assy ♦
32 9332861006 Shaft cover ♦
33 9333951003 Louver spring ♦
3-4. Wall mounted type - (02-42) - 3. Indoor unit parts list
