Item no. Part no. Part name Service part
1 9387480023 Bracket panel ♦
2 9387471007 Louver spring ♦
3 9333608006 Bush ♦
4 9387590050 Drain pan total assy ♦
5 9387714036 Step motor holder assy ♦
6 9901011047 Step motor ♦
7
9332861006 Shaft cover (07-14KETA model) ♦
9332861013 Shaft cover (07-14KETA-B model) ♦
8
9333766072 Blow panel assy (07-14KETA model) ♦
9333766089 Blow panel assy (07-14KETA-B model) ♦
9
9384065001 Cap (screw) L (07-14KETA model) ♦
9384065018 Cap (screw) L (07-14KETA-B model) ♦
10
9384066008 Cap (screw) R (07-14KETA model) ♦
9384066015 Cap (screw) R (07-14KETA-B model) ♦
11 9387711028 Spacer H assy ♦
12
9387479003 U/D louver assy (07-14KETA model) ♦
9387479034 U/D louver assy (07-14KETA-B model) ♦
13
9383613036 Wire cover B (07-14KETA model) ♦
9383613043 Wire cover B (07-14KETA-B model) ♦
14
9387597035 Wire cover assy (07-14KETA model) ♦
9387597073 Wire cover assy (07-14KETA-B model) ♦
15
9387596304 Front panel total assy (07-14KETA model) ♦
9387596311 Front panel total assy (07-14KETA-B model) ♦
16 9333704005 Grille clamper R ♦
17
9384140005 Under cover assy (07-14KETA model) ♦
9384140036 Under cover assy (07-14KETA-B model) ♦
18
9387756159 Intake grille assy (07-14KETA model) ♦
9387756166 Intake grille assy (07-14KETA-B model) ♦
19 9333719009 Grille clamper L ♦
20 9387473018 Air filter ♦
21 9316177017 Drain cap ♦
22 9316904002 Drain hose assy ♦
23 9318912005 Remote controller holder ♦
24 9383712036 Remote controller ♦
a — Step motor holder —
b — Front panel —
3-4. Wall mounted type - (02-47) - 3. Indoor unit parts list
