Item no. Part no. Part name Service part

9387587012 Base assy (07-14KETA model) ♦

9387587050 Base assy (07-14KETA-B model) ♦

51 9383765032 WLAN adapter holder assy ♦

9711141590 Main PCB (For 07 model) ♦

9711141606 Main PCB (For 09 model) ♦

9711141613 Main PCB (For 12 model) ♦

9711141620 Main PCB (For 14 model) ♦

53 9711382009 Display assy ♦

54 9711358004 PWB ASSY ♦

55 9900369057 Terminal ♦

9603768003 Brushless motor (For 07-12 model) ♦

9603631017 Brushless motor (For 14 model) ♦

57 9387589030 Motor case assy ♦

58 9317250009 Air clean filter assy ♦

59 9332911008 Electric filter holder ♦

9387593143 Evaporator total assy (For 07-12 model) ♦

9387593150 Evaporator total assy (For 14 model) ♦

61 9900627041 Thermistor assy ♦

62 9387467000 Room thermistor holder ♦

63 9333628004 Bearing D assy ♦

64 9387055047 Crossflow fan assy ♦

a - Box shield —

b - Control box —

c - PCB holder A —

d - Motion sensor —

e - Front panel cover B assy —

f - Display case assy —

g - Control cover —

h - Motor case —

i - Motor cover —

3-4. Wall mounted type - (02-49) - 3. Indoor unit parts list

TECHNICAL DATA

AND PARTS LIST

TECHNICAL DATA

AND PARTS LIST

Fujitsu ASYG09KETA Service Manual
