Fujitsu ASYG09KETA User Manual

¢
Model: AGYG14KVCA
 Cooling
Octave band sound pressure level, dB: (0 dB=0.0002 µbar)
Octave band center frequency, Hz
80
70
60
50
40
30
20
10
0
63 125 250 500 1,000 2,000 4,000 8,000
HIGH
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
QUIET
 Heating
Octave band sound pressure level, dB: (0 dB=0.0002 µbar)
Octave band center frequency, Hz
80
70
60
50
40
30
20
10
0
63 125 250 500 1,000 2,000 4,000 8,000
HIGH
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
QUIET
- 176 -
9-7. Floor type
9. Noise level curve
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu ASYG09KETA Specifications

General

Cooling Capacity	2.5 kW
Heating Capacity	3.2 kW
Power Supply	220-240V, 50Hz
Refrigerant	R32
Indoor Unit Dimensions (W x H x D)	784 x 270 x 224 mm
Outdoor Unit Dimensions (W x H x D)	663 x 541 x 290 mm
Operating Temperature (Heating)	-15°C to 24°C
