INDOOR UNIT
ASYG07KGTA
ASYG09KGTA
ASYG12KGTA
ASYG14KGTA
2017.09.28 14
31
32
U/D louver assy 9387479003
Ref. Description Part number
Shaft cover 9332861006
33 Louver spring 9387471007
31
32
33
