¢ Model: ASYG18KMTB
Unit: mm
980 240
280
Outline of indoor unit
for pipe inlet Ø65for pipe inlet Ø65
37
37
400 9041377
7341761 429
115
72
2-4. Wall mounted type - (01-25) - 2. Dimensions
