5-7. Outdoor unit
¢
Model: AOYG18KBTA3
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain pipe 1
¢
Model: AOYG24KBTA3
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain pipe 1
Adapter K: mm (in)
12.70 (1/2) to 9.52
(3/8)
1
5-7. Outdoor unit - (02-71) - 5. Accessories
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
