AOYG36KBTA5
Combination no. Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Total
108 7 9 14 24 — 54
109 7 9 18 18 — 52
110 7 12 12 12 — 43
111 7 12 12 14 — 45
112 7 12 12 18 — 49
113 7 12 14 14 — 47
114 7 12 14 18 — 51
115 7 14 14 14 — 49
116 7 14 14 18 — 53
117 9 9 9 9 — 36
118 9 9 9 12 — 39
119 9 9 9 14 — 41
120 9 9 9 18 — 45
121 9 9 9 22 — 49
122 9 9 9 24 — 51
123 9 9 12 12 — 42
124 9 9 12 14 — 44
125 9 9 12 18 — 48
126 9 9 12 22 — 52
127 9 9 12 24 — 54
128 9 9 14 14 — 46
129 9 9 14 18 — 50
130 9 9 18 18 — 54
131 9 12 12 12 — 45
132 9 12 12 14 — 47
133 9 12 12 18 — 51
134 9 12 14 14 — 49
135 9 12 14 18 — 53
136 9 14 14 14 — 51
137 12 12 12 12 — 48
138 12 12 12 14 — 50
139 12 12 12 18 — 54
140 12 12 14 14 — 52
141 12 14 14 14 — 54
142 7 7 7 7 7 35
143 7 7 7 7 9 37
144 7 7 7 7 12 40
145 7 7 7 7 14 42
146 7 7 7 7 18 46
147 7 7 7 7 22* 50
148 7 7 7 7 24 52
149 7 7 7 9 9 39
150 7 7 7 9 12 42
151 7 7 7 9 14 44
152 7 7 7 9 18 48
153 7 7 7 9 22* 52
154 7 7 7 9 24 54
155 7 7 7 12 12 45
156 7 7 7 12 14 47
157 7 7 7 12 18 51
158 7 7 7 14 14 49
159 7 7 7 14 18 53
160 7 7 9 9 9 41
161 7 7 9 9 12 44
162 7 7 9 9 14 46
- 9 -
1-1. Indoor unit connection patterns
1. Model lineup
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
