Fujitsu ASYG14KMCC User Manual

Model: ARXG18KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
-5.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
0.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
5.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
10.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
15.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
20.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
25.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
30.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
35.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52
40.0 3.55 1.64 4.01 1.87 4.23 2.15 4.53 2.41 4.84 2.64 4.99 3.02
46.0 2.30 0.69 2.60 0.78 2.74 0.90 2.94 1.02 3.14 1.11 3.24 1.27
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
 Medium static pressure duct type
Model: ARXG22KMLB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
-5.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
0.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
5.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
10.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
15.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
20.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
25.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
30.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
35.0 6.12 4.03 6.91 4.59 7.29 5.29 7.80 5.94 8.34 6.50 8.60 7.44
40.0 4.53 2.21 5.11 2.52 5.39 2.90 5.77 3.25 6.17 3.56 6.36 4.08
46.0 2.94 0.93 3.32 1.06 3.50 1.22 3.74 1.37 4.00 1.50 4.13 1.72
Model: ARXH22KMTAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
-5.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
0.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
5.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
10.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
15.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
20.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
25.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
30.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
35.0 6.12 4.39 6.91 5.00 7.29 5.76 7.80 6.47 8.34 7.08 8.60 8.11
40.0 4.53 2.41 5.11 2.75 5.39 3.16 5.77 3.54 6.17 3.88 6.36 4.45
46.0 2.94 1.01 3.32 1.15 3.50 1.33 3.74 1.49 4.00 1.63 4.13 1.87
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW).
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 493 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5

Fujitsu ASYG14KMCC Specifications

General

Brand	Fujitsu
Model	ASYG14KMCC
Category	Air Conditioner
Language	English
