Floor type
Model: AGYG09KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
-5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
0.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
15.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
20.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
25.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
30.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
35.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
40.0 1.86 0.94 2.10 1.07 2.21 1.23 2.37 1.38 2.53 1.51 2.61 1.73
46.0 1.20 0.39 1.36 0.45 1.43 0.52 1.54 0.58 1.64 0.64 1.69 0.73
Model: AGYG12KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
0.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
15.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
20.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
25.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
30.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
35.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
40.0 2.49 1.18 2.82 1.35 2.97 1.55 3.18 1.74 3.40 1.91 3.51 2.18
46.0 1.62 0.50 1.83 0.57 1.93 0.65 2.06 0.73 2.21 0.80 2.27 0.92
Model: AGYG14KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
-5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
0.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
15.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
20.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
25.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
30.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
35.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
40.0 2.90 1.34 3.28 1.52 3.46 1.75 3.70 1.97 3.96 2.16 4.08 2.47
46.0 1.88 0.56 2.13 0.64 2.24 0.74 2.40 0.83 2.57 0.91 2.64 1.04
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 507 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
