Model: AOYG18KBTA2
Unit: mm
Side viewSide view Front view
Bottom view Side view (Valve part)
Top view
580
79919 68 16 290
33 30
109
353
632
20
330
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
Airflow
Drain port Ø42
37
114
57104.4
399
150.1
19.7
2-6. Outdoor unit - (01-33) - 2. Dimensions
