¢ Models: ASYG07–14KMCE and ASYG07–14KMCF
Unit: mm
834
270
222
3.0
344 356
327 11332767
62
50
62
84
43
43
Outline of indoor unit
for pipe inlet Ø65 for pipe inlet Ø65
359
418
492
2-4. Wall mounted type - (01-41) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
