Fujitsu AUXG07-18KVLA - Page 120

¢
Model: ARXG22KMLB (Static pressure mode 2)
Fan speed Item
Static pressure (Pa)
35 37 50 55 68 75 93 100
HIGH
m
3
/h
— — — — — — 1160 930
l/s — — — — — — 322 258
CFM — — — — — — 683 547
MED
m
3
/h
— — — — 1020 800 — —
l/s — — — — 283 222 — —
CFM — — — — 600 471 — —
LOW
m
3
/h
— — 835 670 — — — —
l/s — — 232 186 — — — —
CFM — — 491 394 — — — —
QUIET
m
3
/h
660 530 — — — — — —
l/s 183 147 — — — — — —
CFM 388 312 — — — — — —
Q-h Characteristic curve
STATIC PRESSURE(Pa)
110
100
90
80
70
60
50
40
30
500 600 700 800 900 1,000 1,100 1,200 1,300
Airflow (m
3
/h)
COOLING
Cooling capacity(%)
104.0
102.0
100.0
98.0
96.0
94.0
92.0
500 600 700 800 900 1,000 1,100 1,200 1,300
Airflow (m
3
/h)
Capacity
HEATING
Heating capacity(%)
104.0
102.0
100.0
98.0
96.0
94.0
92.0
500 600 700 800 900 1,000 1,100 1,200 1,300
Airflow (m
3
/h)
Capacity
- 112 -
6-3. Medium static pressure duct type 6. Fan performance
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
