15. Accessories

15-1. Model: AOYG30KBTA4

Part name Exterior Q’ty Part name Exterior Q’ty

Installation manual 1

Adapter K: mm (in)

12.70 (1/2) to 9.52

(3/8)

Drain pipe 1

- 375 -

15-1. Model: AOYG30KBTA4 15. Accessories

OUTDOOR UNIT

AOYG30KBTA4

OUTDOOR UNIT

AOYG30KBTA4
