Parts
Exterior Part name Model name Summary
Remote Sensor
Unit
UTY-XSZX
Thermo-sensor for sensing the
temperature of arbitrary place in the
room.
Auto Louver
Grille Kit
UTD-GXTA-W
Width: 683 mm
For 07, 09, 12, and 14 models
Auto Louver
Grille Kit
UTD-GXTB-W
Width: 883 mm
For 18 model
Square Flange UTD-SF045T
Both the Square Flange and the
Round Flange can be selected.
Round Flange UTD-RF204
Round Flange is used when the fresh-
air duct is installed.
Long-life Filter UTD-LF25NA
Long-life Filter can be mounted to the
indoor unit.
Air Cleaning
Filter
UTR-FA16-5
Air Cleaning Filter can be mounted to
the indoor unit.
Drain Pump Unit UTZ-PX1NBA
Optional drain lift up mechanism
allows more flexible installation.
External
Connect Kit
UTY-XWZX
Use to connect with various peripheral
devices and air conditioner PCB.
6-1. Indoor unit - (02-111) - 6. Optional parts
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
