Fujitsu AUXG14KVLA Design & Technical Manual

¢
Model: ARXG18KSLAP
80
70
60
50
40
30
20
10
0
External static pressure (Pa)
700
Airflow (m
3
/h)
900
1,000 1,100
800600
500400
300
Hi (SP mode 05)
SP mode 00
upper limit
Hi (Normal SP)
Normal SP
upper limit
Quiet (Normal SP)
Hi (SP mode 00)
SP mode 05
upper limit
SP mode 05
lower limit
Quiet (SP mode 05)
Quiet
(SP mode 00)
*1: Available airflow rate range when Auto louver grille (option) is installed.
Fan speed: HIGH
Vertical airflow direction louver: Up
80
70
60
50
40
30
20
10
0
External static pressure (Pa)
700
Airflow (m
3
/h)
900
1,000 1,100
800600
500400
300
Available airflow rate range (High level)
*1
Hi (SP mode 05)
Hi (SP mode 04)
Hi (SP mode 03)
Hi (Normal SP)
Hi (SP mode 02)
Hi (SP mode 01)
Hi (SP mode 00)
- 126 -
7-1. Mini duct type
7. Fan performance
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
