7-2. Slim duct type
¢
Model: ARXG07KLLAP
110
100
90
80
70
60
50
40
30
20
10
0
300
400
500
600
700
External static pressure (Pa)
Airflow (m
3
/h)
Hi (SP mode 09)
Hi (Normal SP)
SP mode 09
upper limit
Quiet (SP mode 09)
Normal SP
upper limit
Quiet (Normal SP)
SP mode 00
upper limit
Quiet (SP mode 00)
SP mode 09
lower limit
Hi (SP mode 00)
Normal SP
lower limited
110
100
90
80
70
60
50
40
30
20
10
0
300
External static pressure (Pa)
Airflow (m
3
/h)
400 500
600
700
*1: Available airflow rate range when Auto louver grille (option) is installed.
Fan speed: HIGH
Vertical airflow direction louver: Up
Hi (SP mode 09)
Hi (SP mode 08)
Hi (SP mode 07)
Hi (SP mode 06)
Hi (SP mode 05)
Hi (SP mode 04)
Hi (SP mode 03)
Hi (Normal SP)
Hi (SP mode 02)
Hi (SP mode 01)
Hi (SP mode 00)
Available airflow rate range (High level)
*1
- 128 -
7-2. Slim duct type
7. Fan performance
