Fujitsu AUXG14KVLA Design & Technical Manual

AOYG36KBTA5
Combination no. Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Total
163 7 7 9 9 18 50
164 7 7 9 9 22* 54
165 7 7 9 12 12 47
166 7 7 9 12 14 49
167 7 7 9 12 18 53
168 7 7 9 14 14 51
169 7 7 12 12 12 50
170 7 7 12 12 14 52
171 7 7 12 14 14 54
172 7 9 9 9 9 43
173 7 9 9 9 12 46
174 7 9 9 9 14 48
175 7 9 9 9 18 52
176 7 9 9 12 12 49
177 7 9 9 12 14 51
178 7 9 9 14 14 53
179 7 9 12 12 12 52
180 7 9 12 12 14 54
181 9 9 9 9 9 45
182 9 9 9 9 12 48
183 9 9 9 9 14 50
184 9 9 9 9 18 54
185 9 9 9 12 12 51
186 9 9 9 12 14 53
187 9 9 12 12 12 54
Numbers in column Unit 1 to 5 and Total indicate the indoor unit capacities as follows:
7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h ....
*: As for the 22 model, wall-mounted type indoor unit is only connectable.
- 10 -
1-1. Indoor unit connection patterns
1. Model lineup
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu AUXG14KVLA Specifications

General

Brand	Fujitsu
Model	AUXG14KVLA
Category	Air Conditioner
Language	English
