Fujitsu AUXG14KVLA Design & Technical Manual


Ceiling type
Model: ABYG18KRTA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.69 3.60 3.51 3.42 3.33
-10.0 -11.0 4.59 4.48 4.37 4.26 4.15
-5.0 -7.0 5.46 5.33 5.20 5.07 4.94
0.0 -2.0 6.42 6.27 6.11 5.96 5.81
5.0 3.0 7.06 6.89 6.72 6.55 6.38
7.0 6.0 7.06 6.89 6.72 6.55 6.38
10.0 8.0 7.06 6.89 6.72 6.55 6.38
15.0 10.0 7.06 6.89 6.72 6.55 6.38
20.0 15.0 7.06 6.89 6.72 6.55 6.38
24.0 18.0 7.06 6.89 6.72 6.55 6.38
Model: ABYG22KRTA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.66 4.55 4.44 4.33 4.22
-10.0 -11.0 5.80 5.67 5.53 5.39 5.25
-5.0 -7.0 6.91 6.74 6.58 6.41 6.25
0.0 -2.0 8.12 7.93 7.73 7.54 7.35
5.0 3.0 8.93 8.71 8.50 8.29 8.08
7.0 6.0 8.93 8.71 8.50 8.29 8.08
10.0 8.0 8.93 8.71 8.50 8.29 8.08
15.0 10.0 8.93 8.71 8.50 8.29 8.08
20.0 15.0 8.93 8.71 8.50 8.29 8.08
24.0 18.0 8.93 8.71 8.50 8.29 8.08
NOTES:
• TC: Total Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 440 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4
