Fujitsu AUXG14KVLA Design & Technical Manual

Combination of indoor unit Rated capacity for each indoor unit (kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 4 5 1 2 3 4 5
7 7 9 9 18 50 1.33 1.33 1.71 1.71 3.42 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 9 22* 32 1.23 1.23 1.58 1.58 3.88 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 12 12 47 1.41 1.41 1.82 2.43 2.43 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 12 14 49 1.36 1.36 1.74 2.33 2.71 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 12 18 53 1.25 1.25 1.61 2.15 3.24 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 14 14 51 1.30 1.30 1.68 2.61 2.61 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 12 12 12 50 1.33 1.33 2.28 2.28 2.28 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 12 12 14 52 1.28 1.28 2.19 2.19 2.56 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 12 14 14 54 1.23 1.23 2.12 2.46 2.46 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 9 9 43 1.54 1.99 1.99 1.99 1.99 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 9 12 46 1.44 1.86 1.86 1.86 2.48 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 9 14 48 1.39 1.78 1.78 1.78 2.77 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 9 18 52 1.28 1.64 1.64 1.64 3.30 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 12 12 49 1.36 1.74 1.74 2.33 2.33 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 12 14 51 1.29 1.68 1.68 2.24 2.61 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 9 14 14 53 1.26 1.61 1.61 2.51 2.51 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 12 12 12 52 1.28 1.65 2.19 2.19 2.19 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 9 12 12 14 54 1.23 1.58 2.11 2.11 2.47 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 9 9 9 45 1.90 1.90 1.90 1.90 1.90 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 9 9 12 48 1.78 1.78 1.78 1.78 2.38 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 9 9 14 50 1.71 1.71 1.71 1.71 2.66 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 9 9 18 54 1.58 1.58 1.58 1.58 3.18 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 9 12 12 51 1.68 1.68 1.68 2.23 2.23 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 9 12 14 53 1.61 1.61 1.61 2.15 2.52 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
9 9 12 12 12 54 1.57 1.57 2.12 2.12 2.12 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h, 22: 22,000
Btu/h, 24: 24,000 Btu/h
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB.
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 27,000 Btu up to 54,000 Btu.
• *: As for the 22 model, wall-mounted type indoor unit is only connectable.
- 480 -
6-1. Combinations
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5

Fujitsu AUXG14KVLA Specifications

General

Brand	Fujitsu
Model	AUXG14KVLA
Category	Air Conditioner
Language	English
