Page #491 background image
Combination of indoor unit Rated capacity for each indoor unit (kW)
Total capacity
(kW)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/kWh)
Energy ef-
ficiency
class
1 2 3 4 5 1 2 3 4 5
7 9 9 12 12 49 1.50 1.95 1.95 2.60 2.60 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
7 9 9 12 14 51 1.45 1.87 1.87 2.49 2.92 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
7 9 9 14 14 53 1.40 1.80 1.80 2.80 2.80 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
7 9 12 12 12 52 1.42 1.83 2.45 2.45 2.45 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
7 9 12 12 14 54 1.36 1.77 2.36 2.36 2.75 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 9 9 9 45 2.12 2.12 2.12 2.12 2.12 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 9 9 12 48 1.99 1.99 1.99 1.99 2.64 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 9 9 14 50 1.91 1.91 1.91 1.91 2.96 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 9 9 18 54 1.77 1.77 1.77 1.77 3.52 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 9 12 12 51 1.88 1.88 1.88 2.48 2.48 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 9 12 14 53 1.80 1.80 1.80 2.40 2.80 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
9 9 12 12 12 54 1.76 1.76 2.36 2.36 2.36 3.5 10.60 12.0 0.25 2.36 3.25 4.50 7.0 4.6 A++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h, 22: 22,000
Btu/h, 24: 24,000 Btu/h
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
– Heating: Indoor temperature of 20 °CDB, and outdoor temperature of 7 °CDB/6 °CWB.
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 27,000 Btu up to 54,000 Btu.
• *: As for the 22 model, wall-mounted type indoor unit is only connectable.
- 483 -
6-1. Combinations
6. Capacity table
OUTDOOR UNIT
AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
