¢ Models: ASYG18–24KMTB
Unit: mm
980 240
280
Outline of indoor unit
for pipe inlet Ø65for pipe inlet Ø65
37 37
400 9041377
7341761 429
115
72
417
482
510
- 52 -
4-5. Wall mounted type
4. Dimensions
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
