13. Accessories

13-1. Models: AOYG36KRTA, AOYG45KRTA, and AOYG54KRTA

Part name Exterior Q’ty Part name Exterior Q’ty

Installation manual 1 Drain cap 3

Drain pipe 1 One-touch bush 2

- 82 -

13-1. Models: AOYG36KRTA, AOYG45KRTA, and AOYG54KRTA 13. Accessories

OUTDOOR UNIT

AOYG36-54KRTA

OUTDOOR UNIT

AOYG36-54KRTA
