Brief description of the mainboard
Brief description of the mainb
oard
Information about boards
Be sure to observe the following for boards with ESD:
• You must always discharge static build up (e .g. by touch ing a grounded object)
before working.
• The equipment and tools you use m ust be free of static charges.
• Remove the power plug from the mains s upply before inserting or removing
boards containing ESDs.
• Always hold boards by their edges.
• Never touch p ins or conductors on the board.
An overview of the features is provided in the data sheet.
Special features
You r mainboard is available in different configuration levels. Depending on the c on figuration,
your mainbo ard is e quipped with or supports special features.
This manual describes the most important properties of this mainboard.
Additional information on mainboard s is contained in the "Basic information on mainboard"
manual on the "User Documentation" or "OEM Mainboard" CDs, or on the Internet.
Ports and connectors
The location of the ports a
nd conn ecto rs of your mainboard is specified at the beginning of the manual.
The components and connect
ors ma rked are not necessarily present on t he mainboard.
External ports
The location of the external ports of your mainboard is specified at the be ginning of the manual.
PS/2 keyboard port, pu rple Serial port, turq uoise
Parallel port/Printer, burgundy PS/2 mouse port, green
LAN port (RJ-45)
Microphone port, pink
Audio input (Line in), light blue USB - Un iversal S erial Bus,
black
Audio output (Line out), light green
A26361-D2151-Z212 -1-8 N19, edition 1 English - 1
