Brief description of the mainboard
Installing/removing processor (with heat sink)
Disconnect the system from the mains voltage before performing a ny of the tasks
described below. Details are contained in you r system’s operating manual.
Technical data
• Intel Co re Duo with 800 or 1066 MHz front side bus in the LGA7 75 design (FMB06-65W)
• Intel Pentium 4 w ith 533/800/1066 MHz front side bus in th e LGA775
design (Mainstream FMB 05A)
• Intel Celeron D with 533 MHz Front Side Bu s in the LGA775 design
• A current list of the processors supported by this mainboard is available on the
Internet at: "
http://ts.fujitsu.com/mainb oards".
Never touch the underside of the processor. Even minor soiling such as swea t
from the skin can impair the processor’s operation or destroy the processor.
Place th e processor in the socket with extreme care, as the spring contacts
of t he socket a re very delicate and must not be be nt.
If o ne or more spring contacts are bent do not insert the processor in any case as
it may be damaged by doing so. Please conta ct t he responsible v endor.
2 - English A26361-D2151-Z212-1-8N19, edition 1
