Installing/removin g or rep lacin g p
rocessor (with heat sin k) English - 5
Installing/removing or repla
cing
processor (with heat sink)
Disconnect the system from the mains voltage before performing any of the tasks
described below. Details are contained in the operating manual of your system.
Technical data
• D2703-S:
AMD Mobile Turion, AMD Mobile Sempro n, max. 35 W in der Bauform S1
• D2703-A:
AMD Mobile Sempron, max. 9 W in S1 design
Procedure
1
2
1
1
2
► Remove any fan and the heat sink.
► Use a flat
head screwd river. Turn the screw (1) 180° a nti-clockw ise.
► Remove the processor from the slot ( 2).
► Insert
the new processor in the slot.
► Turn the screw (1) 180° clockwise.
The so
cket with the processor clicks into place.
Plea
se note that, de pending on the heat sink used, d ifferent heat sink
moun
ts are required on the mainboard.
► Depend ing on the configuration variant, you must pull a protective foil off the heat sink
or coat the heat sink with heat conducting paste before fitting it.
Fujitsu Technology Solutions 19
