D2759 (TX150 S7) Technical Manual 25
Features PCI slots
The following interrupt signals are used in the system:
Assignment of the PCI interrupts
If you select Auto in the BIOS setup, the interrupts are assigned automatically
and no further settings are required.
Slot/device Property Interrupt signal
VGA iRMC S2 graphic PCI-INTD
LAN Intel 82574L PCI-INTC
Slot 6 PCIe x8 PCI_INTA, PCI_INTB,
PCI_INTC, PCI_INTD
Slot 5 PCIe x8 PCI_INTA, PCI_INTB,
PCI_INTC, PCI_INTD
Slot 4 PCIe x1 PCI_INTA, PCI_INTB,
PCI_INTC, PCI_INTD
Slot 3 PCIe x1 PCI_INTA, PCI_INTB,
PCI_INTC, PCI_INTD
Slot 2 PCIe x4 PCI_INTA, PCI_INTB,
PCI_INTC, PCI_INTD
Slot 1 PCI (33 MHz) INTB, INTC, INTD, INTA
