Brief descript ion of mainboard
Graphics controller
• Intel GMA 4500
Typical resolution (colour depth up to 32 bits/pixel)
1024 x 768 (recommended)
1280 x 1024 (recommended)
1600 x 1200 (recommended)
1440 x 900 Widescreen TFT (VGA/DVI)
1680 x 1050 W idescreen TFT (VGA/DV I)
1920 x 1200 W idescreen TFT (VGA/DV I)
Other resolutions are possible depending on the monitor.
Installing/removing the processor
Disconnect the system from t
he mains voltage before performing any of the tasks
described below. Details ar
e conta ined in the operating ma nual of your system.
Technical data
• Base LGA775, max. 95W
• Intel® Core
TM
2 Quad Q9xxx / Q8xx processors, LGA775 with 1333/1066 MHz FSB
• Intel® Core
TM
2DUOE8xxx/E6
xxx processors, LGA 775 with 1333/1066 MHz F SB
• Intel® Core
TM
2 DUO E7xxx / E4xxx processors, LGA775 with 1066/800 MHz FSB
• Intel® P en tium® Dual Core E2x
xx processors, LGA775 with 800 MHz F SB
• Intel® Celeron® Dual Core E1xxx processors, LGA775 with 800 MHz FSB
• Intel® Celeron® 4xx processo
rs, LGA775 w ith 800 MHz FSB
• A current list of the processors supported by this mainboard is available on the
Internet at: "
http://ts.fujitsu.com/mainb oards".
Never touch the underside of the processor. Even minor soiling such as grease
from the skin can impair the processor’s operation or destroy the processor.
Place th e processor in the socket with extreme care, as the spring contacts
of t he socket a re very delicate and must not be be nt.
If one or more spring contacts are bent , on no account insert the processor as it
may b e damaged by doing so. Please contact the responsible vendor.
2 - English A26361-D2831-Z 212-1-8N 19, edition 1
