Fujitsu PSN 900 Plus - Chapter 1 Specifications

2
Chapter1 Specifications
PSN 900 Plus PVID Specifications and Parameters Table:
No. Item Specifications
1 Dimension(L)*(W)*(H) mm 302mm*132mm*38mm
2 Material ABS
3 Colour Black
4 Weight Less than 2kg
5 Touch screen 5.0 inches (resolution: 800 * 480)
6 Types of supported RF cards Mifare S50/S70/Desfire, ID / HID(optional)
7 Memory Capacity 4GB
8 Speaker 1*1W
9 USB2.0 Interface 1
10 Communication Interface
Electric lock / Exit Button/ Alarm
Wiegand 26/34,Corporate 1000,CSN32 (connected with access
controller, Max 50m)
LAN（10/100M）
11 Power DC: 12V/1.5A (DC 12V±5%)
12
Operating
Environment
Temperature
Humidity
0℃ ~ 50℃; relative humidity: 30 ~80%, No condensation
Note: The product is only suitable for indoor installation
Lighting
Environment
Enrollment
Authentication
Natural light (sunlight)
<2000Lux <3000Lux
Fluorescent lamp light <2000Lux <3000Lux
halogen light
<500Lux <700Lux
13 Work Mode
Palm Vein (1:N) Note: These three
modes support
separate card swiping.
PIN Code+Palm Vein (1:1)
Group + Palm Vein (1:G)
Card + Palm Vein (1:1)
14
False Reject Rate (FRR) <0.01% Note:According to ISO/IEC19795 algorithm
False Accept Rate (FAR) <0.00001%Note:According to ISO/IEC19795 algorithm
15 User Capacity
Max users
1000 IDs (1:N Mode)
40,000 IDs (1:1 Mode, extensible)
>500 IDs 1:1 Mode (recommended)
<500 IDs 1:N Mode (recommended)
16
Authentication
Speed
1: N Mode <2.5s (<500IDs)
1: 1 Mode <1s
17 Event Log Records in the last 6 months
