Figure 1. Configuration with no TV Tuner
Figure 2. Configuration with TV Tuner and Direct Signal
Remote
Control
To dedicated
USB port
Remote
Control
IR Receiver
Remote
Control
IR Receiver
Remote Control
To designated
USB port
RF Coaxial
cable to cable
connector
or antenna
Antenna
Adapter
Cable
