432011.03.18
INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF
ASU9RLF
ASU12RLF
21
22 Joint Pipe Assy
Evaporator Total Assy
23
Holder (Room Thermistor)
Thermistor Assy
24
25 Evaporator Holder R
26
Filter Guide
Parts number
DescriptionRef
9317820011
9317838009
9317652001
9317651004
9317650007
9317649001
27
Rear Bracket
28
29
Evaporator Holder L
Distributor Assy 9318579000
9316895003
9900563004
21
28
29
22
23
24
26
25
27
