Page #11 background image
BRANCH BOX
UTP-PY02A
Unit : mm
Ceiling hanging
Indoor unit side
Outdoor unit side
Wall hanging
2010.10.28 10
216
469
469
432
433
75
195
85 68
95
256
372
148 25
75 7095
152
24
174
154
110
176
134
