72
2010.10.08
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LJCA
ASYG09LJCA
ASYG12LJCA
21
22
Joint Pipe Assy
Evaporator Total Assy
23
Holder (Room Thermistor)
Thermistor Assy
24
25
Evaporator Holder R
26
Filter Guide
Parts number
Description
Ref
9317820011
9317838009
9317652001
9317651004
9317650007
9317649001
Rear Bracket
27
28
Evaporator Holder L
9316895003
9900563004
21
27
28
22
23
24
26
25
75
77
Table of Contents
Table of Contents
1
Specifications
2
Electrical Data
6
Fan Motor
6
Dimensions
9
Refrigerant System Diagram
21
Pipe Length
22
Additional Charge
22
Circuit Diagram
23
Outdoor Pcb Circuit Diagram
33
Branch Box Pcb Circuit Diagram
39
Indoor Pcb Circuit Diagram
43
Wall Mounted
49
Error Detection
63
Parts (Outdoor Unit)
68
Parts (Branch Box)
72
Parts (Indoor Unit)
75
Accessories
113
