SERVICE PARTS INFORMATION 6
Choke Coil / Reactor assy (INV)
Reactor assy
Reactor assy
Check Point 1 : Appearance check
Check Point 2 : Electric check
Set the tester to the "Resistance" mode, and check for open/short between both ends of the reactor wire
(or connector).
Judge the result of as follows:
Short : Normal
Open : Abnormal (open)
No fissures, breaks, damage, etc. at the body and winding section, terminals section?
Reactor assy (INV)
04-117
