- 130 -

Waterstage / Maintenance Manual / 2105 - EN

▼

Pipe cover front removal

by sliding upward.

Remove the RIGHT PANEL

Remove the mounting screws.

Screws

Remove the mounting screws. Remove the PIPE COVER FRONT.

Hooks

(serrated)

screw

(with washer)

screw

▼

Right panel removal
