- 118 -

Waterstage / Maintenance Manual / 2105 - EN

Makre sure that the wires are not pinched when you close the SERVICE PANEL.

Caution

by sliding downward.

Remove the SERVICE PANEL

Remove the mounting screws.

Hooks (4 places)

(serrated)

Screws

►

3 phase type

▼

Appearance

▼

Service panel removal
