- 66 -
Heating Circuit Assignment
Line Nr Programming line
70 Software version
Software version
The indication shows the current version of the user
interface.
▼
Time Program Functions (heating circuit 1 & 2, DHW, cooling)
Several control programs are available for the heating circuits and the production of DHW. They are initiated in
"Automatic" mode and control the change in temperature levels (and therefore the associated setpoints, reduced
and comfort) via the adjusted changeover times.
Enter changeover times
Changeover times can be adjusted in a combined way, i.e., identical times for several days or distinct times for
certain days. Preselecting groups of days (e.g., Mon...Fri and Sat...Sun) having the same changeover times makes
adjustment of the changeover program considerably shorter.
Standard Program
Line Nr Programming line
516, 536, 576, 616 Default values (No /Yes)
All time programs can be reset to factory settings.
Each time program has its own command line for this
reset action.
In this case, individual settings will be lost !
Holidays
Line Nr Programming line
HC1 HC2
642 652 Period start (Day / Month)
643 653 Period end (Day / Month)
648 658 Operating level
The holiday program enables changing the heating
circuits over to a selected operating level according to
the date (calendar).
Important !
The holiday program can be used only in the automatic
mode.
Changeover Points
Line Nr Programming line
HC1 HC2 4/DHW 5
500 520 560 600 Preselection (Mon-Sun / Mon-Fri / Sat – Sun / Mon...Sun)
501 521 561 601 1st phase On
502 522 562 602 1st phase Off
503 523 563 603 2nd phase On
504 524 564 604 2nd phase Off
505 525 565 605 3rd phase On
506 526 566 606 3rd phase Off
Waterstage / Maintenance Manual / 2105 - EN
