5
Red LED is
always on
The battery is damaged when the charger
is connected.
Red LED is
always on
No AC input, DC output from charger
connected to battery.
Green LED is
always on
After the maintenance indicator turns
twice, the power indicator (green) is
always on.
Charging
percentage LED
light
During the charging process, 25% or
50% or 75% charging LED will ash
slowly. Indicates the charging status and
displays the current battery capacity.
When the battery is about to be fully
charged, the 100% charge LED will slowly
ash. When the battery is fully charged,
the 100% charge LED will turn solid white.
The charger can be connected to the
battery indenitely.
PROBLEM DIAGNOSIS
Use «Problem Diagnosis» when an error is displayed, it will
display a series of red LED ashing phenomena to help you de-
termine the error.
The number of ashes indicates the corresponding fault (see list
for details).
Malfunction
Cause/Solution
Error LED - Single
ash
When the DC output is reversed
connection, the Error red LED
ashes once and goes off once.
Error LED - Double
ash
When the AC output is short-cir-
cuited the Error red LED ashes
twice and goes out once.
Power LED - Triple
ash
When the charging is in the overheat
protection state, the Power red
LED ashes three times and goes
out once.
Power LED - Red light
always on
The charger is connected to an un-
corrected battery or the battery is
damaged. Have the battery checked
by a professional.
MAINTENANCE
The charger is maintenance free. If the power cord is damaged,
the charger must be left to the reseller for maintenance. The
case should be cleaned occasionally. The charger should be dis-
connected from the power while cleaning.
For indoor use only.
Do not expose to rain.
WEEE - Waste Electrical & Electronic Equipment
Do not dispose of Waste Electrical & Electro-
nic Equipment in with domestic rubbish.
