KNOW YOUR PRODUCT

• 3.0HP, 50L TANK

• 164L/MIN FREE

AIR DELIVERY

• DUAL PRESSURE

GAUGES

• 2 AIR OUTLETS

INSTRUCTION MANUAL

WARNING: Read all safety warnings and all instructions. Failure to follow the

warnings and instructions may result in electric shock, ﬁre and/or serious injury.

Save all warnings and instructions for future reference.

1015

V-TWIN AIR

COMPRESSOR

Table of Contents

Questions and Answers:

T
Tiffany JohnsonAug 3, 2025
What to do if my Full Boar FBACVT-5030 Air Compressor does not start?
- A
  Amber MaldonadoAug 3, 2025
  If your Full Boar Air Compressor isn't starting, here's what to check: * First, the compressor might have reached its cut-out pressure. If so, it will automatically start once the pressure drops below the cut-in point. * Check that the power supply, plug, and socket are all working correctly. * If using an extension lead, try shortening it to ensure sufficient power. * The compressor should never be operated when the outside temperature is below 5¼C. * Allow the motor to cool down. If necessary, remedy the cause of the overheating. * Finally, reset the overload switch.
K
Kayla HahnAug 17, 2025
Why is my Full Boar FBACVT-5030 starting but not building pressure?
- J
  Jeremy Thompson DVMAug 17, 2025
  If your Full Boar Air Compressor starts but doesn't build pressure, consider these potential issues: 1. A leak in the non-return valve might be the cause, in which case you should replace the valve. 2. Damaged seals can also prevent pressure build-up. Check the seals and have them replaced by a service center if needed. 3. Ensure that the drainage valve is completely shut off, as leaks here can prevent the compressor from reaching pressure.

Full Boar FBACVT-5030 Specifications

General

Model	FBACVT-5030
Max Pressure	135 PSI
Power Source	Electric
Maximum Pressure	135 PSI
Voltage	230V
Phase	Single
Pump Type	Oil-lubricated

Summary

Specifications

Know Your Product

Overload Switch

Component for motor overload protection.

Intake Air Filter

Filters air entering the compressor.

Pressure Tank

Stores compressed air.

ON/OFF Switch

Main control for powering the compressor.

Regulated Pressure Gauge

Indicates regulated output air pressure.

Pressure Regulator

Adjusts output air pressure.

Safety Relief Valve

Safety device to release excess tank pressure.

Unregulated Air Outlet

Connection for unregulated compressed air.

Introduction

Safety Instructions

Electrical Safety

Guidelines for safe electrical connections and usage.

Using an Extension Lead

Safe practices for using extension cords.

General Power Tool Safety Warnings

Work Area Safety

Ensures a safe operating environment.

Electrical Safety

Precautions for electrical connections and usage.

Personal Safety

User protection measures.

Power Tool Use and Care

Proper operation and maintenance guidelines.

Service

Instructions for professional servicing.

Assembly

Fitting the Wheels

Step-by-step guide to attach wheels.

Fitting the Supporting Feet

Instructions for attaching the support feet.

Replacing the Air Breather

Procedure for installing the air breather.

Intake Air Filter Assembly

Steps to assemble the air filter components.

Intake Air Filter Installation

How to attach the assembled air filter.

Operation

Switching ON/OFF

Instructions for turning the compressor on and off.

Adjusting the Pressure

How to set the output air pressure.

Checking the Safety Relief Valve

Procedure to verify the safety valve function.

Maintenance

Cleaning

Instructions for cleaning the compressor exterior.

Removing Condensed Water

Procedure for draining water from the tank.

Safety Relief Valve Maintenance

Information on the safety relief valve.

Check Oil Level

Guidance on monitoring and refilling compressor oil.

Changing the Oil

Steps for draining and refilling the engine oil.

Cleaning the Intake Air Filter

Procedure for cleaning the air filter.

Storage

Guidelines for storing the compressor.

Trouble Shooting
