H6028FB/H6028FBO/H6028BR/H6028BRO/
H6033FB/H6033FBO/H6033BR/H6033BRO PARTS LIST
No. Description Qty
1 Right-Angle Fitting 1/2" 2
2 Welded Hose 1
3 Low Pressure Return Hose 1
4 Right-Angle Fitting 1 1
5 Control Valve 1
6 Valve Straight Fitting 1/2" 1
7 Right-Angle Fitting 1 1
8 High Pressure Supply Hose 1
9 Latch Rod 2 2
10 Beam Pivot Pin 1
11 Cylinder 1
12 Bolt M14×85 1
13 Washer 14 3
14 Wedge 1
15 Locknut M14 1
16 Beam Weldment 1
17 Washer 6 6
18 Beam Pivot Pin 1
19 Pin 6×40 2
20 Beam Pivot Pin 1
21 Dipstick 1
22 Bridge Pin
∮
4 1
23 Pivot Bracket 1
24 Washer 10 8
25 Bolt M10×30 4
26 Spring1 1
27 Flat Washer 12 9
28 Spring Washer 12 4
29 Nut M12 4
30 Tank Assemly 1
31 Nut M8 4
32 Spring Washer 8 12
33 Washer 8 22
34 Engine 1
35 Washer 8 GB/T96 4
36 Safety Clasp 2
No. Description Qty
37 Pump Bracket 1
38 Cover of Pump Bracket 1
39 Screw M4×8 4
40 Spring Washer 4 4
41 Washer 4 4
42
Bolt M8×25 only for H6028FB/
H6028FBO/H6033FB/H6033FBO
4
Bolt 5/16-24 UNF only for
H6028BR/H6028BRO/
H6033BR/H6033BRO
43 BoltM12×85 2
44 Key 3/16×30 1
45 Gear Pump Connector Right 1
46 Elastic Spider Block 1
47 Bolt M6×8 4
48 Gear Pump Connector Left 1
49 Gear Pump 1
50 Bolt M8×20 6
51 Outlet connector of Pump 1
52 Bolt M6×16 6
53 Washer 6 6
54 Flange of lter 1
55 O-Ring D81×3.1 1
56 Return oil lter 1
57 Suction Hose 1
58 Clamp18-32 2
59 Manual Tube 1
60 Nut M10 5
61 Flat Washer 10 4
62 Safety Chain 2
63 Support leg Weldment 1
64 Latch Rod 2 1
65 Bridge Pin
∮
3 1
66 Clamp25-38 2
67 2" Ball Coupler Hitch 1
68 Bolt M12×80 2
69 Bolt M10×85 1
No. Description Qty
70 Dust Cap 2
71 Axle Nut M22 2
72 Wheel Washer 22 2
73 Tire 2
74 Bearing 4
75 Anti-Dust Washer 2
76 Latch Rod 1 1
77 Cotter Pin 4×50 2
78 Spring2 1
79 Key 3×25 1
80 Bracket Weldment 1
81 Bolt M8×25 4
82 Nut M8 4
83 Bolt M8×40 4
84 Beam Lock Bracket 1
No. Description
Qty
1* Log Catcher 1
2* Bolt M10×30 2
3* Nut M10 2
4* Flat Washer 10 2
LOG CATCHER (SOLD SEPARATELY)
38
Gas Log Splitter
»
Operator’s Manual
Parts List
|
