5
1. Pull the twist lock upward, and rotate clockwise to the         
"OPEN"positiontoopenthetopcompartment.
2. CleanorreplacetheTopPrefilter.
3. Vacuum the inside of the top compartment to remove        
anyaccumulatedparticles.
The top compartment should be cleaned periodically (at least        
weekly)topreventprematurecloggingofthefilteringsystem.

5.2 LowerFilterCompartment
1. The bottom compartment contains 1x HEPA Filter and       
4xActivatedCarbonFiltercartridges.
2. Pull the two twist locks upward and rotate clockwise to         
the"OPEN"positiontoopenthefrontgate.
3. Grasp the handle on the top cartridge and pull out each          
ofthefilterelementsonebyone.
4. After replacement, put the elements back in sequence       
frombottomtotoplayerbylayer.

5.3 SuctionDuctHoseInstallation
Remove the hose from the package, and attach one end of the           
top 4” air inlet duct of the machine and the other end to your             
Full Spectrum Laser machine’s outlet duct. Optionally you may        
connect another hose (not included) to the bottom air outlet port          
to vent the air outside. It is not normally not necessary to vent            
theairoutside.

Donotintroduceabendradiusofmorethan10”onthehose.

5.4 MachineOperatingInstructions
Pluginandcheckifthepowerplugisproperlyfitintothesocket.
Turnonthepowerswitch. 
