» General Heat Demand: Congures the output as a General Heat
Demand. The output will enable whenever any of the boilers receive
a heat demand.
» System Pump #: Congures the output for the System Pump. The
output will enable when the corresponding system pump receives a
demand. This selection will only be available if System Pumps have
been enabled.
» Boiler # Heat Demand: Congures the output as a boiler heat
demand status. The output will enable whenever the corresponding
boiler has a heat demand.
FIGURE 12 – DIGITAL OUTPUT HARDWARE CONFIGURATION SCREEN
 Digital Inputs: All digital inputs need to be congured for the options
desired before the inputs will operate. Only options that have been
enabled will be selectable along with some precongured default options.
All digital inputs are 24VDC and dry contacts should be provided for all
inputs.
» Boiler # Valve Interlock: Congures the input for the boiler
isolation valve status interlock. When the boiler receives a heat
demand the ModSync® will enable the isolation valve and then waits
for the isolation valve status interlock input to be received before
sending the enable to the boiler. This selection will only be available
if isolation valves and isolation valve interlocks have been enabled.
» Boiler # Pump Interlock: Congures the input for the boiler
circulation pump status interlock. When the boiler receives a heat
demand the ModSync® will enable the boiler pump and then waits
for the pumps status interlock input to be received before sending
the enable to the boiler. This selection will only be available if
boiler circulation pumps and circulation pump interlocks have been
enabled.
